The Best Dayton 410 Hp Automatic Submersible Pump

Top discharge is perfect for tight spaces where water removal is needed laundry tubs, window wells, buckets, bathtubs, etc. Side discharge is ideal for easy water removal from flat open surfaces: flat roofs, flooded basements, standing water in yard, shower stalls, etc. 30 ft. Max head removes water down to 1/16 in. Of surface, virtually dry! multi-ring suction strainer filters debris, and minimizes clogs

4″ deep well submersible pump. 2 HP, 230V, 10.2 Amps, 12 stage, 1-1/4” NPT discharge Industrial grade heavy duty, also good for home usage
* Fits a 5″ or larger well casing.
* Patented impeller & 12 stage design. 35GPM max & 400ft head are greater than almost all other 2HP well pumps, and comparable to 3HP pumps, but uses less electricity.
* Unique floating impeller design, premium seal, and UL qualified motor provide long life for this pump.
* Water temperature: (32 ~113of) Trans medium’s Ph.: 6.5~ 8.5
* Shell, motor shaft are made with stainless steel to ensure corrosion resistance.
* High quality sealed ball bearings guarantee its excellent performance.
* Built in check valve included. Installing external check valve(s) is required.
* Hermetically sealed motor with capacitor start, and thermal protection to prevent overheating, for longer life and powerful start.
* Built in control box. This pump DOES NOT require an external control box!
* This pump uses high quality and high efficient UL approved motor, UL file No.: E233961, for less energy and long pump life.
* This is a 2 wire pump with 3-Wire (2 wires + ground wire) 10′ long electric cord included.
* Heavy-duty thermoplastic impellers, diffusers, and intake screen.
* Unique design reduces its noise. User’s manual and installation tape kit included.
* 400 feet max head is for open water tanks. Refer to the ‘Pump Selection Guide’ for the pressure tank applications.
* Warranty: 12 months manufacturer’s warranty

Deep Well Submersible Pump, 1/2HP, 220V/60HZ/1PH, 25 GPM Max, 150 Feet MAX, S.S. SHELL C.I Intake, 1.25 NPT discharge. Brand new product in the box! NOT ‘Manufacturer Refurbished’. We are based in the U.S., customer services, tech support & warranty are handled in the U.S.
FEATURES:
* 4″ deep well S.S submersible pump, 1/2HP, 220V, 3.3 Amps, 150 Feet MAX Head, 25 GPM Max
* Fits a 5″ or larger well casing. For 4″ casing, use pump MA0460X-9A, or MA0459X-14A;
* Patented impeller provides heavy duty higher performance and longer life than most other well pumps.
* Solid stainless steel body with heavy duty cast iron discharge
* Industrial grade heavy duty, also good for home usage.
* Built in 1/2 HP capacitor start, and thermal protection switch. For longer life and powerful start.
* Built in control box. This pump DOES NOT require an external control box!
* This pump uses high quality UL approved motor, UL file No.: E233961
* This is a 2 wire pump with 3-Wire (2 wires + ground wire),10′ long electric cord included
* 1.25″ NPT discharge
* Heavy-duty thermoplastic impellers, diffusers, and intake screen.
* This is a 2 wire pump with 3-Wire (2 wires + ground wire).
* Submersible design eliminates the need for priming and creates quiet operation.
* High efficiency and hermetically sealed motor has thermal protection prevents overheating, uses less energy.
* 150 Max head is for open water tank. The max head will be reduced in pressure tanks. Read the ‘Selection Guide’ for details!
* Installation manual, and tape kit are included.
* Free technical support available during installation.
* Warranty: 12 months limited manufacturer’s warranty

SUBMERSIBLE WIRE SPLICE KIT INCLUDED WITH EVERY PUMP PURCHASE!

IMPORTANT: THIS PUMP DOES NOT REQUIRE A CONTROL BOX!

Our Deep Well Pump is ideal for the supply of fresh water to rural homes, farms, and cabins that have 4 inch and greater diameter drilled wells. It is a durable workhorse that will keep you in flow for years to come. Brand new pump in the box! NOT ‘Manufacturer Refurbished’.

-The pump has a thermally protected motor with a 95°F maximum work temperature to keep from overheating while in use.

-2-wire + ground wire design for easy provision and energy efficiency.

-Stainless steel casing keeps this pump sturdy and functioning for years.

-The well pump submersible is easy to install and extremely versatile.

-Patented impeller design provides high flow up and high head, for better performance and longer life than most other well pumps.

-This pump model features a built in check valve, however this check valve is only used to prevent water from going back in the pump and causing backspin of the impellers, but if you are going to use the pump in a pressure system YOU NEED TO USE AT LEAST ONE EXTERNAL CHECK VALVE IN THE PIPE, the valve in the pump won’t fulfill that function.

-1 year warranty.

NOTICE: Our pumps are checked for physical damage before they’re shipped. As soon as you receive it check for any damage that might have occurred during shipping, and please report it to Amazon if you see any.

NOTICE 2: This pump is designed to be used in clear pure water only, even an small amount of sand diluted in the water will damage it, make sure your well pumps clear water before you install it, this is important because damages caused by sand are not covered by the warranty.

Product Description

Superior Pump builds pumps that are truly Built to Last and are 100 percent factory tested. Superior Pump uses quality components including solid copper motor windings, heavy duty stainless steel jacketed shaft seals, double o-ring seals on motor plate, and electronically controlled split capacitors. Superior Pump model 91250, 1/4 HP thermoplastic submersible utility pump with 10 foot power cord and ¾-inch garden hose adapter, will move water up to 1800 gallons per hour. Equipped with suction screen to filter out large debris and handles up to 1/8-inch solids with ease. Base of the pump is designed to fit the hub of a standard 6-inch floor drain. This pump is UL/CUL listed and CSA certified and backed by a 1 year warranty.

Amazon.com

The Superior Pump 1/4-Horsepower Submersible Utility Pump offers exceptional power in a small, durable frame. Able to pump 30 gallons a minute up to 25 feet of vertical height, this tough submersible pump features durable thermoplastic construction and a compact design that can fit inside a 6-inch opening. Designed to drain standing water from any enclosed environment, the Superior Pump is ideal for flooded basements, farm use, and typical residential or commercial water transfer applications. An optional float switch can be added to allow this model to be used as a sump pump.

1/4-Horsepower Submersible Utility Pump At a Glance Powerful, 1/4-horsepower, continuous-duty split capacitor motor Efficient pump is capable of pumping up to 30 gallons a minute Can lift water up to 25 feet vertically for versatile use Durable, corrosion-resistant thermoplastic construction Backed by a one-year limited warranty

Click here to see the cutaway view.

Continuous duty motor can pump up to 30 gallons a minute and lift water up to 25 feet vertically. View Larger.

Performance Chart View Larger.

Designed for Consistent, Reliable Domestic Use
Ideal for draining standing water from swimming pools, fountains, and flooded basements, the Superior Pump can move up to 30 gallons a minute, whisking away water to an 1/8-inch to the ground. Fully submersible, the Superior Pump features a 10-foot, replaceable, waterproof power cord, and is able to lift water up to 25 feet vertically. It’s equipped with a large 1-1/4-inch male iron pipe discharge thread for high capacity pumping, and includes a garden hose adapter for your convenience. With the addition of an optional float switch, the Superior Pump can also be used as a sump pump.

Continuous-Duty Motor Powers Through Tough Jobs
The Superior Pump showcases a continuous-duty, split capacitor motor for optimal performance. Thermally protected, this high-efficiency, 3.8-amp, 1/4-horsepower motor delivers the power necessary for any tough job.

Rugged, Compact Design for Durability
Durable thermoplastic construction ensures this submersible pump can be used time and again without corroding. With a sleek, compact design, the Superior Pump can fit inside an opening as small as 6 inches. Water intakes on the side and bottom of the pump allow for continuous pumping with clog-resistant suction.

Product and Warranty Information
This pump is UL/CUL listed and CSA certified for safety and dependability.

The Superior Pump Submersible Utility Pump is backed by a one-year limited warranty.

What’s in the Box
Utility pump, hose adapter, and user manual.

Choose the right thermoplastic pump for you:
	91025	91250	91330	92250	92330	92333
Horsepower	1/5 hp	1/4 hp	1/3 hp	1/4 hp	1/3 hp	1/3 hp
Amps	3.6	3.8	4.1	3.8	4.1	2.76
Gallons Per Minute	25 GPM	30 GPM	40 GPM	30 GPM	30 GPM	50 GPM
Discharge Size	1-1/4 inches	1-1/4 inches	1-1/4 inches	1-1/4 inches – 1-1/2 inches	1-1/4 inches – 1-1/2 inches	1-1/4 inches
Discharge Type	Top	Top	Top	Top	Top
Switch Type		Tethered		Tethered	Tethered

See all Product description

Product Description

3/4 hp, cast iron/stainless steel, submersible sump pump, with vertical switch, designed for 11 inch diameter or larger sump basin, pumps up to 4600 gph at 0′, durable cast iron volute, reliable, reinforced poly carbonate impeller, corrosion resistant stainless steel motor housing & fasteners, top suction design filters debris & minimizes clogging, oil filled, thermally protected motor prevents overheating, designed for easy installation without any Plumbing changes, epoxy coated steel, high performance 3/4 hp, motor, 1-1/2 inch NPT discharge & durable cast iron base, easy carry handle for portability, float guard protects switch from hang ups, 5 year warranty. This product is assembled in the USA. Easy installation and easy handling.

From the Manufacturer

The Wayne CDU980E submersible sump pump can move up to 4600 gallons per hour (gph). The top suction design filters debris and minimizes clogging. It is a rugged, stainless steel and cast iron submersible sump pump. This pump is designed for 11-Inch diameter and larger sump pits.
